Product Characteristics:
Corner protection
Seamless splicing
High grey scale & High contrast
Stainless steel fast lock

Product Characteristics:
Corner protection
Seamless splicing
High grey scale & High contrast
Stainless steel fast lock
Pixel Pitch | P3.79 indoor | P3.84 indoor | P3.79 outdoor | P3.84 outdoor | P4.8 outdoor |
Module Size(mm) | 288*288 | 288*288 | 288*288 | 288*288 | 288*288 |
Module Resolution | 76*76 | 75*75 | 76*76 | 75*75 | 60*60 |
Scan Mode | 19S | 25S | 19S | 15S | 10S |
LED Configuration | 1921 | 1921 | 1921 | 1921 | 1921 |
Brightness(nit) | ≥600 | ≥600 | ≥4000 | ≥4000 | ≥4000 |
Driving Method | constant current | constant current | constant current | constant current | constant current |
Refresh Rate | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 |
Grey Scale | 16bit | 16bit | 16bit | 16bit | 16bit |
Constant Color Range | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
Viewing Angle(H/V) | ≥140°/≥140° | ≥140°/≥140° | ≥140°/≥140° | ≥140°/≥140° | ≥140°/≥140° |
Contrast Ratio | 5000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 |
Module Input Voltage(V) | 5V | 5V | 5V | 5V | 5V |
Module Max Current | 7A | 7A | 12A | 7A | 7A |
Max Power(W/㎡) | 450 | 450 | 720 | 720 | 720 |
Average Power(W/㎡) | 150 | 150 | 240 | 240 | 240 |
IP Level | IP42 | IP42 | IP65 | IP65 | IP65 |
Input Voltage(V) | 110-220 | 110-220 | 110-220 | 110-220 | 110-220 |
Display Weight | 8.2kg | 8.2kg | 8.2kg | 8.2kg | 8.2kg |
Display Thickness | 85mm | 85mm | 85mm | 85mm | 85mm |
Life Time(Hours) | ≥100000 | ≥100000 | ≥100000 | ≥100000 | ≥100000 |
Working Temperature | -20°C~+50°C | -20°C~+60°C | -20°C~+60°C | -20°C~+60°C | -20°C~+60°C |
Working Humidity | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH |
Certification | FCC/CE/RoHS/BIS |
